Input Voltage: +12 V/DC (11.4V - 12.6V) | Current: Max. 16A Output Power: 160W
Power Efficiency: 92%
Operating Temperature: -5°C to 55°C 24 pin
24 way ATX Connector goes to motherboard
Additional Cabled Connectors:
SATA Power x1, 4/8 pin 12V for CPU power, 4 way stiffy drive x1, 4 way Molex for DVD/HDD x1
DC Input Connector: Plug with 2.5mm inner diameter 5.5mm outer diameter
Unit Size: 5.4 cm x 3.3 cm
